4
Warning
1. Opening the stroller
2. Assembling the front wheels
3. Automatic front wheel swivel locks
4. Using the brakes
II.- I Wheel systems check
II.- II Applying the lubricant
Rear wheels - Spray from the rear side of the buggy in the space between
the rim and the housing on both sides. Let the lubricant work its way into the
system for approx. 10 seconds and then turn both rear wheels.
Front wheels - Spray in the space between the rim and the housing on both
sides. Let the lubricant work its way into the system for approx. 10 seconds
and then turn both front wheels. If the squeaking continues, remove the rim
cap and apply the spray on the axle.
b)
a)
The wheel system must be cleaned before applying the lubricant
The wheel system must not be broken or damaged. To avoid squeaking noises
on your CYBEX stroller use a multi-function oil such as WD 40 and follow the
instructions below. To avoid staining the fabrics protect them by covering them
with a cloth or carton before applying the lubricant .
Please pay special attention to avoid applying the lubricant on any other parts
of the stroller (fabrics, tubes, etc.)
b)
a)
Push the front swivel lock lever until it “clicks”. It can be activated in any wheel
position.The swivel lock will engage automatically once the wheel swivels are
in the correct position. To release the swivel lock push the front swivel lock
lever again.
a)
Engage brake.
Release brake.
b)
a)
Fit the front wheels to the end of the frame until they snap in.
III. Instructions for use
IMPORTANT: Keep these instructions for future reference. Read these instructions
carefully before use. Your child‘s safety may be affected if you do not follow these
instructions.
Release the fold lock lever.
Open the stroller.
b)
a)
c) Push down the pedal of the primary lock lever until the locking system is
engaged.
Ensure that all locking devices are engaged before use.
