9
ADJUSTING THE HEADREST
The adjustable Headrest (22) can be adjusted by using the Headrest adjustment
handle (23). When adjusting the Headrest (22) ensure that no more than 2 cm
(approx. 2 finger's width) remain between the child's shoulders and the headrest.
SECURING THE CHILD
1. Press the Belt adjustment button (24) and pull both Shoulder belts (25) at the
same time to loosen them.
2. Undo the Belt buckle (26) by pressing the red button firmly.
3. Put your child in the car seat with their buttocks at the back.
4. Place the Shoulder belts (25) directly over your child's shoulders.
5. Place both Buckle tongues (27) together and lock them in place in the Belt
buckle (26). You should hear an audible "CLICK".
6. If you are using a seat with a SensorSafe Clip, push the clip closed until you
hear an audible "CLICK" and slide the closed clip down towards the Belt
buckle (26).
7. Pull on the Central adjustment belt (28) to tighten the Shoulder belts (25) until
they rest snug against your child's body.
💡
The harness should be fitted tight enough so that it is not possible to put a fold
in any of the straps.
8. When using the SensorSafe clip, position the clip directly below the shoulder
pads.
ROTATION FUNCTION
The rotation function is only available in combination with the Base Z. Push the
Green button (29) on the Seat rotation slider (30) to the side and then pull the
entire slider outwards. Now you can turn the seat.
Before starting your journey, make sure that the car seat is properly locked into
place and the Driving direction indicator (31) shows GREEN.
ADJUSTING THE SUN CANOPY
Unfold the Sun canopy (32) by pulling on the plastic cover.
ADJUSTING THE LYING POSITION OUTSIDE THE VEHICLE
The car seat can be brought into the lie-flat position by pressing the release
handle for the lie-flat position (33) while simultaneously shifting the back section
downwards.
TRAVEL SYSTEM
You can attach the car seat to any approved stroller. Click the car seat onto
the approved adapter, facing the parent. To unlock, hold down the two Release
buttons for the stroller adapter (34) and lift them up.
REMOVING AND REATTACHING THE SEAT COVER
The car seat cover consists of 6 parts. These are fastened to the car seat at
several places. Once unfastened, the individual parts of the cover can be removed.
To reattach the cover, follow the removal instructions in the reverse order.
💡
The cover may only be washed at 30°C with a delicate wash program otherwise
it may result in discolouration of the cover fabric. Please wash the cover
separately from other laundry and do not dry it in the dryer or in direct sunlight!
MANUFACTURER'S WARRANTY AND DISPOSAL REGULATION
CYBEX GmbH (Riedingerstr. 18, 95448 Bayreuth, Germany) gives you 3 years
warranty on this product. The warranty is valid in the country where this product
was initially sold by a retailer to a customer. The contents of the warranty and all
essential information required for the assertion of the warranty can be found on
our homepage: go.cybex-online.com/manufacturer-warranty-car-seats. If a
warranty is shown in the article description, your legal rights against us for defects
remain unaffected.
Please observe the waste disposal regulations in your country.
EN
