1) Machine Description
2 - Start/stop, speed regulation knob
3 - Tiltable table
4 - Feeding table
5 - Locking lever of tiltable table
6 - Display unit
7 - Delivery table
8 - X stop
9 - Y stop
10 - Stop setting scale
11 - Side guides
12 - Side guides skew regulation
13 - Stop slider
14 - Feeding wheel
15 - Table of paper folds
16 - Socket with electric switch
17 - Half-fold switch
18 - Locking bolt of the side guide
19 - Table for straight perforation
20 - Table thrust regulation
21 - Perforating wheel
22 - Cover of perforation unit
23 - Stripper
24 - Table of delivery modes
25 - Delivery wheels
26 - Stop wheel
27 - Bush
28 - Creasing wheel
29 – Support collar
