How to troubleshoot a Cynosure Apogee Elite laser that does not start?
If your Cynosure Measuring Instruments laser does not start, ensure the power cables are connected and the laser’s main circuit breaker is in the on position. Also, verify that the keyswitch is turned to START and has returned to ON.
What to do if Cynosure Apogee Elite Measuring Instruments shows a 'Low Water' message?
If you see a 'Low Water' message on your Cynosure Measuring Instruments, add distilled water to the fill level. If the fault continues, check for loose electrical connections and the functionality of the level switches.
Why won't my Cynosure Apogee Elite Measuring Instruments laser enter Ready Mode?
If your Cynosure Measuring Instruments laser will not enter Ready Mode, make sure the operator switch is not activated by checking that the finger switch or foot switch is not being pressed. Also, ensure the Ready Key is activated by pressing it.
What to do if my Cynosure Apogee Elite says 'No Fiber'?
If your Cynosure Measuring Instruments displays 'No Fiber,' install a fiber and press any key to continue. Check the fiber interlock switches in the cal port, and replace them if necessary, as the fiber interlock may be open.
Why won't my Cynosure Apogee Elite laser go into Standby Mode?
If your Cynosure Measuring Instruments laser will not go into Standby Mode, allow the laser to run until the WARM UP message disappears. Check for any other fault messages and correct those conditions. Also, make sure the Standby Key is activated by pressing it.
How to fix 'Open Interlock' error on Cynosure Apogee Elite?
If your Cynosure Measuring Instruments displays an 'Open Interlock' message, check whether the external interlock is open. Also, check for a bad electrical connection and replace if necessary.
What does 'Invalid Handpiece' mean on Cynosure Measuring Instruments?
If your Cynosure Measuring Instruments displays 'Invalid Handpiece', the handpiece sensed cannot be used. Install an appropriate handpiece.
What to do if Cynosure Apogee Elite shows 'No Lamp Simmer'?
If lamps are not simmering in Standby Mode on your Cynosure Measuring Instruments, check that both lamps flicker. If not, check the lamps and simmer circuit. If the lamps are simmering, check that the ends of fiber 90 are smooth and shiny and verify fiber 90 is securely connected at DR4 on the Interface PCB and CR1 Simmer PCB.
Why won't my Cynosure Apogee Elite Measuring Instruments laser fire outside of the Cal Port?
If the Ready LED is lit but the Cynosure Measuring Instruments laser will not fire outside of the Cal Port, recalibrate the laser. Ensure the handpiece fiber cable is properly connected and check that the foot switch connector is properly inserted into the foot switch receptacle.
What should I do for a 'Power Supply Warning; Cycle Power' message on Cynosure Measuring Instruments?
If your Cynosure Measuring Instruments displays a 'Power Supply Warning', turn the system off and then on to test if the problem recurs. If the fault continues, replace the HVPS and recalibrate it.
General| Brand | Cynosure |
|---|---|
| Model | Apogee Elite |
| Category | Measuring Instruments |
| Language | English |
Details optical and electrical hazards associated with laser systems.
Warns about eye damage from laser light and provides safety precautions.
Describes electrical dangers and necessary safety measures during servicing.
Explains grounding procedures to prevent electrical shock.
Outlines precautions to prevent fire risks when operating the laser.
Warns about scalding hazards from the laser's hot water system.
Provides an overview of the primary components of the laser systems.
Describes the function and specifications of the HVPS.
Details the fuse board's role in protecting storage capacitors.
Explains the capacitor bank's function and energy storage capacity.
Describes the subsystem that stores and delivers energy to flashlamps.
Explains the function of the IGBT driver board in controlling the IGBT.
Details the IGBT's role as a switching device and the snubber module's function.
Describes the simmer board's function and trigger transformer operation.
Outlines the function of the system control board, microprocessor, and software.
Describes the laser head or pump chamber assembly.
Explains the system that maintains the laser medium temperature.
Defines the standards for a properly working laser system.
Outlines a sequence for checking system and resonator performance.
Details the procedure for replacing the high voltage power supply.
Details the process of calibrating the laser's built-in energy meter.
Details the steps for a final functional and performance check.
Introduces common faults and diagnostic procedures.
Describes errors caused by improper operation and how to correct them.
Lists fault codes, their descriptions, and causes/solutions.
Explains critical faults that stop laser operation and require service.
Lists critical fault codes and their corresponding clear messages.
