9
When the application launches (see the image below) the user can
select the following features.
1
2
3
4
5
6
1
RS232 ComPort and Baud Rate Setting: Click 'Connect' to conrm
the transmission setting and connect to the CLUX-UCEC
2
CEC Commands and Data Setting
3
CEC Basic Command Buttons
4
EDID Read, Write, Save File and Load File Buttons
5
RS232 ComPort Communication Log Window
6
RS232 ComPort Communication Log Window Control Buttons
Step 2-1:
Select the COM Port (Refer to Step 2 in Section 7.2) and set the UART
BaudRate to 115200 and press the "Connect" button. From this step
onwards users can start to send or receive CEC commands.
