7
5. FEATURES
Supports TMDS equalisation and CDR (Clock Rate Recovery) for
extended HDMI cable range.
Input/Output Resolutions: Output resolution follows Input: PC: VGA
(640
×
480) to WUXGA/RB (1920×1200); HDTV: 480i to 1080p + 1080P
24fps.
Requires HDMI source to output power via HDMI cable to power
Enhancer (2W as standard).
RE-HDEQ is capable of receiving and transmitting 2.25Gbps.
Supports HDMI cable distance of 15m either side of the device at full
1080p.
No PSU required
6. OPERATION CONTROLS AND FUNCTIONS
1
HDMI input: Connect the HDMI input to the HDMI output of your
source equipment such as Blu-ray player or HDMI switcher/HDMI
Splitter/HDMI Matrix. The unit can be directly powered from HDMI
source equipment that provides power through the HDMI cable or by
a RE-PI Power Inserter connected between the source and the unit.
2
HDMI output: Connect the HDMI output to the HDMI input of a HDMI
transmitter or TV/display.
