INSTALLATION Cyrus DAD7
English
6
Upgrading with a
Cyrus PSX-R
Intelligent Power
Supply (Optional)
When upgrading with a PSX-R Intelligent power supply,
only one connection is necessary to the DAD7. The
Cannon connector fitted to the umbilical cable on the
PSX-R must be securely connected to the socket marked
PSX-R
4
on the rear of the DAD7. When correctly fitted,
the connector will latch into place in the socket. Note that
when a PSX-R is in use, both the PSX-R power supply
and
the DAD7 will require connection to the mains supply.
Connecting to an External D/A Converter (Optional)
The DAD7 also supplies a digital output signal which can
drive an external D/A converter if desired, such as the
Cyrus Dacmaster. Using a single RCA interconnect
designed for digital signals, connect from the socket
marked SPDIF OUT
1
to an input of the D/A converter
(the CD input is recommended for best performance when
using the Cyrus Dacmaster). Ensure that you use a cable
specifically designed for use with digital data, rather than
an audio phono cable. Use of the wrong type of cable may
cause a mismatch between components and degrade sound
quality. Referring now to the D/A converter handbook,
connect the D/A converter audio outputs to a suitable
input of the amplifier.
