Let's Make

Step 9: Then attach crocodile clips to the servo extension

cable as shown.

Step 8: Connect the servo motor cable to the servo

extension cable.

Step 10: Attach the other end of the white cable to Pin-2

of the micro:bit, red cable to Pin-3V and black cable to

Pin-GND.

Servo Motor Cable

Brown

Red

Orange

White

Black

Servo Extension Cable
