Czerf CZE-05B - All Configurations

4
5. All configurations
NO.
project
1
working voltage
11~13V DC
2
working current
<300mA
3
frequency domain
76~108Mhz
4
frequency stability
±10PPM
5
stepped frequency
100KHZ
6
The operating temperature of
the environment
-10℃~50℃
7
output impedance
50Ω
8
Rf power output range
H:500mW (L:100mW)
9
Harmonic and noise radiation
≤-60dB
10
audio distortion
<0.3%
11
frequency response
20HZ~15000HZ
12
Preemphasis delay
50us
13
degree of separation
≥40 dB
14
input level
≤-10dBV
15
Modulation frequency deviation
±75KHZ
16
SNR(Signal to Noise Ratio)
≥65 dB
17
Machine Size
113*88*38mm
18
Machine weight
269g
