D-Link AirPlus G DWL-G510

Getting Started (continued)
Settin
g
u
p
a Wireless Infrastructure Network
For a typical wireless
setup at home (as shown
above), please do the
following:
2
1
3
4
DWL-G510
6
5
DWL-G630
You will need broadband Internet access (a Cable or DSL-subscriber line into
y
our home or office
)
.
Consul
t
with
y
our Cable or DSL
p
rovider for
p
ro
p
erinstallationof the modem.
Connec
t
the Cable or DSLmodem to your broadband router.
(
See the Quick Installation Guide included with
y
our router
)
.
Install the D-Link AirPlus
®
G DWL-G510 Wireless G Desktop Adapter
into an available PCI slot on your desktop computer.
(
See the Quick Installation Guide included with the network ada
p
ter
)
.
Install the D-Link DWL-G630 Wireless G Notebook
A
dapter into a laptop computer.
(
See the Quick Installation Guide included with the DWL-G630
)
.
If you wish, you may connect a computer that is equipped with an Ethernet net-
work ada
p
ter
(
such as a DFE-530TX+
)
to the router also.
9
