ANT24-0700 Install Guide Hardware Overview
Hardware Overview
The magnetic base
allows you to set the
antenna on a fl at surface
or attach to a wall.
Magnetic Base
Connects to the SMA
connector on your
wireless device.
Extension Cable
Converts a SMA connector to
a TNC connector type.
SMA to TNC Adapter
Warning: The base unit is magnetic. Keep magnetic base at least 6 inches away from
electronic devices; computers, TV’s, video equipment, and tapes. Exposure to magnetic
base may cause device or data on disks to become corrupted.

D-Link ANT24-0700 Specifications

General

Brand	D-Link
Model	ANT24-0700
Category	Antenna
Language	English
