D-Link ANT24-0700 User Manual

6
D-Link Systems, Inc.
ANT24-0700 Install GuideAntenna Installation
Connecting the Antenna
The ANT24-0700 attaches to the SMA connector that is
standard on most D-Link
®
products. Simply disconnect
your existing antenna and connect the cable from the
ANT24-0700 to the SMA connector on your D-Link
®
product.
The ANT24-0700 also includes an SMA to TNC connector
for attaching the ANT24-0700 to products with a TNC
connector.
