D-Link COVR-2202 Reviewer's Guide

17
18
C100 M0 Y19 K23
Pantone 3145C
Network
Management
The Covr Tri-Band Seamless Wi-Fi
System provides you with a home
network solution that is quick and easy
to set up. The Covr Points work straight
out of the box - just plug them in to get
started. Congure your network in no
time using the intuitive web-based
interface or with the free D-Link Wi-Fi
app for your Android or iOS mobile
device. Adding new wireless devices to
your Covr network is a snap thanks to
the Wi-Fi Protected Setup (WPS) button,
which establishes an instant connection
to new devices without the need to enter
settings or create passwords. Expand
your network with the touch of a button.
Connected Clients
Check the status of individual devices
connected to your Covr network by
clicking on this icon. The name and IP
address of each device will be displayed
in the panel at the bottom of the screen.
Click on the edit icon in the top
right-hand corner of each device tile
to manage that specic device.
Extenders
You can check the status of each Covr
Point by clicking this icon. Click on the
edit icon for each Covr Point to change
its display name. Clients connected to
Covr Points will also be displayed here.
Network Status
Click on the Covr Point icon to get a
snapshot of your network, including
device IP address, IPv6 address,
Wi-Fi network status, Wi-Fi Name,
and Password.
C100 M0 Y19 K23
Pantone 3145C

D-Link COVR-2202 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	1000 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Internal	No
Placement	Table
Certification	FCC, IDA, IC, CB, CE, LVD, RCM, RoHS
Product color	Gold, White
Number of products included	2 pc(s)
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	20 W
Security algorithms	WPA, WPA2, WPS
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Antennas quantity	6
Package depth	367 mm
Package width	260 mm
Package height	108 mm
Package weight	2396 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1299 mm
Pallet height (sea)	1881 mm
Pallet gross weight (air)	272600 g
Pallet gross weight (sea)	397400 g
Quantity per pallet (air)	96 pc(s)
Quantity per pallet (sea)	144 pc(s)
Shipping (inner) case width	384 mm
Shipping (inner) case height	291 mm
Shipping (inner) case length	458 mm
Shipping (inner) case weight	10400 g
Shipping (inner) case net weight	9584 g
Number of cartons per pallet (air)	24 pc(s)
Number of cartons per pallet (sea)	36 pc(s)
Quantity per shipping (inner) case	4 pc(s)

Weight and Dimensions

Depth	90 mm
Width	100 mm
Height	200 mm
Weight	690 g
