DES-3200 Series
Hardware Version
A1 B1 A1 B1
Interface
Size
9-inch Desktop Size, 1U Height 9-inch Desktop Size, 1U Height 9-inch Desktop Size, 1U Height 9-inch Desktop Size, 1U Height
Interface
8 10/100BASE-TX
2 Combo 1000BASE-T/SFP
8 10/100BASE-TX
1 SFP
1 Combo 1000BASE-T/SFP
16 10/100BASE-TX
2 Combo 1000BASE-T/SFP
16 10/100BASE-TX
1 SFP
1 Combo 1000BASE-T/SFP
Console Port
RS-232 RJ-45 RS-232 RJ-45
Performance
Switching Capacity
5.6 Gbps 5.6 Gbps 7.2 Gbps 7.2 Gbps
64-Byte Packet
Forwarding Rate
4.2 Mpps 4.2 Mpps 5.4 Mpps 5.4 Mpps
MAC Address Table-Size
8K Entries 8K Entries 8K Entries 8K Entries
SDRAM for CPU
128 MB 128 MB 128 MB 128 MB
Packet Buffer
384 KB 384 KB 384 KB 384 KB
Flash Memory
16 MB 16 MB 16 MB 16 MB
Jumbo Frame
(2048 Bytes Tagged,
2044 Bytes Un-Tagged)
LEDs
Power (Per Device)
Console (Per Device)
Link/Activity/Speed
(Per Port)
Physical and
Environmental
MTBF (Hours)
873,750 hours 804,462 hours 743.115 hours 764,596 hours
Acoustic
0 dB 0 dB 0 dB 0 dB
Heat Dissipation
43.3 BTU per hour 31.3 BTU per hour 45.0 BTU per hour 36.4 BTU per hour
Power Input
100 to 240 VAC, 50 to 60 Hz Internal Universal Power Supply
Max Power Consumption
12.7 watts 9.2 watts 13.2 watts 10.7 watts
Dimensions (W x D x H)
228.5 x 180 x 44 mm 228.5 x 195 x 44 mm 228.5 x 180 x 44 mm 228.5 x 195 x 44 mm
Ventilation
Fanless Fanless Fanless Fanless
Power Surge Protection
-
All Ethernet ports support
IEC61000-4-5 10/700us 6 KV surge
protection
-
All Ethernet ports support
IEC61000-4-5 10/700us 6 KV surge
protection
Operating Temperature
0 to 40 ˚C (32 to 104 ˚F) 0 to 50 ˚C (32 to 122 ˚F) 0 to 40 ˚C (32 to 104 ˚F) 0 to 50 ˚C (32 to 122 ˚F)
Storage Temperature
-40 to 70˚ C (-40 to 158˚ F)
Operating Humidity
5% to 95% non-condensing
EMI
FCC Class A, CE Class A, VCCI Class A, IC, C-Tick
Safety
CE LVD, UL/cUL, CB
3rd Party Certifications
MEF 21, IPv6 Ready Logo
Technical Specifications
DES-3200-10 DES-3200-18
