03
DES-3200 Series
Hardware Version
A1 B1 A1 B1
Interface
Size
19-inch Standard Rack-Mount
Width,
1U Height
19-inch Standard Rack-Mount
Width,
1U Height
19-inch Standard Rack-Mount
Width,
1U Height
19-inch Standard Rack-Mount
Width,
1U Height
Interface
24 10/100BASE-TX
2 Combo 1000BASE-T/SFP
24 10/100BASE-TX
2 Combo 1000BASE-T/SFP
24 10/100BASE-TX
2 SFP
2 Combo 1000BASE-T/SFP
24 10/100BASE-TX
2 SFP
2 Combo 1000BASE-T/SFP
Console Port
RS-232 RJ-45 RS-232 RJ-45
Performance
Switching Capacity
8.8 Gbps 8.8 Gbps 12.8 Gbps 12.8 Gbps
63-Byte Packet
Forwarding Rate
6.6 Mpps 6.6 Mpps 9.5 Mpps 9.5 Mpps
MAC Address Table-Size
8K Entries 8K Entries 8K Entries 8K Entries
SDRAM for CPU
128 MB 128 MB 128 MB 128 MB
Packet Buffer
384 KB 384 KB 384 KB 384 KB
Flash Memory
16 MB 16 MB 16 MB 16 MB
Jumbo Frame
(2048 Bytes Tagged,
2044 Bytes Un-Tagged)
LEDs
Power (Per Device)
Console (Per Device)
Link/Activity/Speed
(Per Port)
Physical and
Environmental
MTBF (Hours)
566,381 hours 697,861 hours 668,867 hours 668,867 hours
Acoustic
0 dB 0 dB 0 dB 0 dB
Heat Dissipation
47.0 BTU per hour 46.3 BTU per hour 48.4 BTU per hour 48.4 BTU per hour
Power Input
100 to 240 VAC, 50 to 60 Hz Internal Universal Power Supply
Max Power Consumption
13.8 watts 13.6 watts 18.4 watts 14.2 watts
Dimensions (W x D x H)
441 x 207 x 44 mm
Ventilation
Fanless Fanless Fanless Fanless
Power Surge Protection
-
All Ethernet ports support
IEC61000-4-5 10/700us 6 KV surge
protection
-
All Ethernet ports support
IEC61000-4-5 10/700us 6 KV surge
protection
Operating Temperature
0 to 40 ˚C (32 to 104 ˚F) 0 to 50 ˚C (32 to 122 ˚F) 0 to 40 ˚C (32 to 104 ˚F) 0 to 50 ˚C (32 to 122 ˚F)
Storage Temperature
-40 to 70˚ C (-40 to 158˚ F)
Operating Humidity
5% to 95% non-condensing
EMI
FCC Class A, CE Class A, VCCI Class A, IC, C-Tick
Safety
CE LVD, UL/cUL, CB
3rd Party Certifications
MEF 21, IPv6 Ready Logo
Technical Specifications
DES-3200-26 DES-3200-28
