Appendices:
Appendix A
Select a PHY address(for DFE-853 and DFE-854)
Switches 1 through 5 are used to set PHY addresses.
PHY
Address
DIP Switch #
SW1 SW2 SW3 SW4 SW5
00h OFF OFF OFF OFF OFF
01h OFF OFF OFF OFF ON
02h OFF OFF OFF ON OFF
03 h OFF OFF OFF ON ON
04h OFF OFF ON OFF OFF
05h OFF OFF ON OFF ON
06h OFF OFF ON ON OFF
07h OFF OFF ON ON ON
08h OFF ON OFF OFF OFF
09h OFF ON OFF OFF ON
0Ah OFF ON OFF ON OFF
0Bh OFF ON OFF ON ON
0Ch OFF ON ON OFF OFF
0Dh OFF ON ON OFF ON
0Eh OFF ON ON ON OFF
0Fh OFF ON ON ON ON
10h ON OFF OFF OFF OFF
11h ON OFF OFF OFF ON
12h ON OFF OFF ON OFF
13h ON OFF OFF ON ON
14h ON OFF ON OFF OFF
15h ON OFF ON OFF ON
16h ON OFF ON ON OFF
17h ON OFF ON ON ON
18h ON ON OFF OFF OFF
19h ON ON OFF OFF ON
1Ah ON ON OFF ON OFF
1Bh ON ON OFF ON ON
1Ch ON ON ON OFF OFF
1Dh ON ON ON OFF ON
1Eh ON ON ON ON OFF
1Fh ON ON ON ON ON
