5D-Link DIR-2055 User Manual
Section 1 - Product Overview
Back Panel
1
1
Gigabit LAN Ports
(1- 4)
Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game
consoles.
2 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
3 Reset Button
Insert a paperclip in the hole, wait for 10 seconds, and release to reset the router to default
settings.
4 WPS Button
Press to start the WPS process and automatically create an encrypted connection to a WPS
client.
5 Wi-Fi Button Press to enable or disable Wi-Fi.
6 Power Connector Connector for the supplied power adapter.
7 Power Button Press the power button to power the device on or o.
2 3 4 5 6 7
