D-Link DIR-506L Quick Installation Guide

1
DIR-506L
ENGLISH
Package Contents
LAN
ON
OFF
5V
LAN
ON
OFF
5V
+
-
Insert and Charge the Battery
USB Cable (for power and charging battery only)
Rechargeable Battery
SharePort Go
1. The battery must be installed for the device to operate. Slide off
the cover and insert the battery. Make sure the gold contacts align
with the gold terminals. Slide the cover back on.
2. Connect the USB cable to the DIR-506L and then connect to a USB
port on your computer.
Note: Charge the device using the USB cable for at least 4 hours or
until it is fully charged before usage.

D-Link DIR-506L Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports	1
USB version	2.0
Rack mounting	No
DHCP client	-
Antennas quantity	2
Security algorithms	WEP, WPA, WPA2, WPS
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	22.3 mm
Width	102.9 mm
Height	79.8 mm
Weight	125 g
