7
Deploying: WAN using Static IP Addressing or PPPoE
OPTION 2:
If your ISP Modem/Gateway requires Authentication or Static IP Addressing, follow these
steps to properly congure your Fuzion™ Router:
Step A: Connect any LAN port on the Fuzion™ Router directly to your computer
using an Ethernet cable. Connect the power unit to the router. Do not block the
vents on the router to prevent overheating.
Step B: Launch a web browser and type the IP address of the Fuzion™ Router
(http://192.168.3.17)
Step C: Once you enter the IP address, the login screen will appear. Enter your
username and password and then click Log In.
DIR-605 Computer
To Next Page
