6D-Link DIR-802 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 Power LED
A solid green light indicates a proper connection to the power supply. The light will blink orange during
boot up.
2 Internet LED
A solid light indicates connection on the Internet port. If the LED is orange, the connection is good but the
router cannot connect to the Internet.
3 WPS LED This LED blinks during WPS handshake phase.
4 Wireless LED A solid light indicates that the wireless segment is ready. This LED blinks during wireless data transmission.
5 Local Network LEDs
A solid light indicates a connection to an Ethernet-enabled computer on ports 1-4.
This LED blinks during data transmission
21 43 5
