6D-Link DIR-857 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and hubs.
2 Internet Port
The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable
or DSL modem.
3 USB Connect a USB 1.1, 2.0, or 3.0 ash drive to congure the wireless settings using WCN.
4 Reset Press and hold the reset button to restore the router to its original factory settings.
5 Power Button Press the power button to power on and o.
6 Power Receptor Receptor for the supplied power adapter.
1 2 3
4
5
6
