D-Link DIR Series User Manual

6) If there is a MAC clone policy from your
ISP then clone the MAC address of your
Router or the PC and click next.
7)
Click on Connect.
8) Router will reboot and the settings
will get applied. Again Login into
the device and go to Status and
check the status of internet. You can
see Internet connection status,
DHCP client established and got the
IP address from the ISP.
HOW TO CONFIGURE THE INTERNET:-

D-Link DIR Series Specifications

General

Wireless Standard	IEEE 802.11ac
Frequency Band	Dual-band (2.4 GHz and 5 GHz)
Wireless Speed	Up to 1200 Mbps
Ethernet Ports	4 x 10/100/1000 Mbps
WAN Ports	1 x 10/100/1000 Mbps
USB Ports	1 x USB 2.0
Security Protocols	WPA, WPA2, WPA3
Antenna Type	External antennas
