D-Link DSL-2888A Quick Installation Guide

DSL-2888A
4
ENGLISH
Step 5
If you are setting up the DSL-2888A using a device with
wired Ethernet, plug one end of the supplied Ethernet cable
into the port labeled LAN1 on the back of the modem router,
and the other end into the Ethernet port on your computer.
If you are setting up the DSL-2888A using a device with
wireless Ethernet, connect to one of the following wireless
networks:
D-Link-2.4G
D-Link-5G
DSL-2888A
Power
PC
PC
Step 4
Connect the supplied power adapter to the modem router and
a power outlet, and press the power button. The device LEDs
will light up. Wait approximately one minute. Verify that the
Power, DSL, 2.4G, and 5G LEDs are lit green before going on
to the next step.
DSL-2888A
Power
PC
Step 6
Open a browser on the connected computer. Go to 192.168.1.1
and enter admin for the username and admin password. Click
the Quick Setup link and follow the on-screen instructions.
• Change the default passwords of your devices. Always use unique
passwords and change them periodically. Keep your passwords safe and
only share them with those you trust.
• Encrypt your wireless networks with the strongest method supported.
• Be sure to check the D-Link website periodically for the latest rmware,
drivers, and software updates.
TAKE PRECAUTIONS
TIPS TO HELP PROTECT YOUR NETWORK
!
Log In
Admin Password:

D-Link DSL-2888A Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-11
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	1600 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11u, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	5
Firewall security	Dual Active Firewall
Security algorithms	WPA, WPA2, WPS-PBC, WPS-PIN
Product type	Tabletop router
Product color	Black
Antenna type	3x3
Antennas quantity	3
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Certification	CE, FCC, LVD, RCM

Weight and Dimensions

Depth	37 mm
Width	155 mm
Height	230 mm
Weight	523 g
