DWL-700AP User’s Manual
40D-Link Systems, Inc.
Barker (1Mbps/0db)

Barker (2Mbps/3db)

CCK (5.5Mbps/5.5db)
CCK (11Mbps/8.5db)
5% - 95%, non-condensing
Humidity:

Modulation Techniques


15dBm +/- 2dB
Transmitter Output Power:

Operating Temperature:
32ºF to 131ºF (0ºC to 55ºC)

Power (Green)
Link (Green)
TX/RX (Green)
LEDs:



Power Input:
External Power
Supply: DC 5V, 2.4A

Warranty:
1 Year

Weight:
.44 lbs. (200g)

Safety & Emissions
FCC
UL


Device Management
Web-Based - Internet
Explorer v5 or later;
Netscape Navigator v4 or
later; or other Java-enabled
browsers.

Tolerates up to +17dBm at
the Antenna
Over-Driving Levels:

External Antenna Type:
2.5dB gain with reverse
SMA connector

L = 5.5 inches
(140mm)
W = 4.5 inches
(114mm)
H = 1 inches
(25.4mm)
Physical Dimensions:



Technical Specifications (continued)
Technical Specifications
