D-Link DWL-8500AP

D-Link Corporation 3
DWL-3500AP/8500AP Installation Guide
Floor 2
Floor 1
Data Center
Server
Farm
DWS-3024
Wireless Switch
Floor 2
Floor 1
Data Center
Server
Farm
DWS-3024
Wireless Switch
DWS-3024
Wireless Switch
D-Link Unified Access System Deployment
• Overlay T opology
Deploy into the existing infrastructure
without affecting the wired network.
The AP can be indirectly connected to
D-Link wireless switch.
• Edge Switch T opology
Deploy at the network edge for maximum
scalability.
The AP can be directly connected to and
powered by D-Link wireless switch.
