11D-Link DCS-8010LH User Manual
Section 2 - Installation
Place the baseplate over the holes that are in the wall. Make sure to
align the baseplate holes with the holes in the wall. Use the supplied
screws to attach the baseplate to the surface of the wall.
4/
Place the camera over the baseplate with the alignment nub pointing
left, then attach the camera by rotating it until the alignment nub
points up.
5/
Adjust the angle and rotation of the camera as desired. You can also
rotate the camera on the baseplate about 45° to the right or left.
6/
