3D-Link DCS-8010LH User Manual
Section 1 - Product Overview
Hardware Overview
Front
1 Status LED Refer LED Behavior on page 5 for more information.
2 Microphone Picks up sound near your camera.
3 Camera Lens Records video of the surrounding area.
4 Infrared LEDs Illuminate the camera’s eld of view in low light environments.
5 Light Sensor
The IR-Cut removable sensor monitors lighting conditions and switches between
color and infrared accordingly.
6 Camera Stand Used to mount the camera on a at surface.
1
2
4
5
6
3
