D-Link NetDefend DFL-210

3.1 Connecting Firewall to Your Network
A. First, connect the power cord to the receptor at the back panel
of the DFL-210 and then plug the other end of the power cord to
a wall outlet or power strip. Now the Power LED will turn ON to
indicate proper operation.
B. 1. Powered off your Cable or DSL modem; some devices may
not have a on/off switch and will require you to unplug the power
adapter. Now, the DFL-210 should be powered on and the Cable
/ DSL modem should be turned off.
2. Cable / DSL modem (Powered Off) - DFL-210 (Powered On)
Connect an Ethernet cable to the Ethernet jack located on
the Cable / DSL modem. After the Ethernet cable is securely
connected, powered on the Cable / DSL modem by turning on
the unit or plugging in the power adapter.
3. Cable / DSL modem (Powered On) - DFL-210 (Powered On)
Insert the other end of the Ethernet cable to one of the Ethernet
ports on the rear panel of the DFL-210. The WAN port LED
light will illuminate to indicate proper connection. If the LED
light is not illuminated, please go back to step B and repeat its
instructions.
C. Insert an Ethernet cable to the LAN1 port on the rear panel of
the DFL-210 and connect it to a port on your network hub or
switch. The LAN port LED light on the DFL-210 will illuminate to
indicate proper connection
D. Connecting the computer that you will use to congure the
DFL-210 to the network hub or switch.
Connecting the DFL-210
3
04
