D-Link ShareCenter DNS-323

6D-Link DNS-323 Quick Install Guide
Hardware Installation
1. Accessthedrivebaysbyslidingthefaceplateupuntilitunlatches
fromthedevice.
2. Oncethefaceplateisunlatched,pullitoffofthedevice,exposing
thedrivebays.
3. Inserta 3.5” SATA hard driveinto each available drivebay.
Makesuretoalignthedriveconnectorstotheendpointsinthe
DNS-323.Gentlypushthedriveinuntilitconnects.
Note: If only one 3.5” SATA drive is
available place this drive in the LEFT bay
with the opening (front) of the DNS-323
facing you.
