15
Programmable output 4
No. Name Range Factory Setting
o400 Function of output 4 0 - 4 0
0 Disabled
1 Position indication/Movement/Warning. Signal as congured in o410 – o422
2 Presence detection/Direction sensing. Signal as congured in o491
3 Lock
4 Alarm output Signal as congured in o430 – o442
o410 Open position 0 - 2 0
0 Disabled
1 Constant signal
2 Flashing signal
o411 Mid position 0 - 2 1
0 Disabled
1 Constant signal
2 Flashing signal
o412 Closed position 0 - 2 1
0 Disabled
1 Constant signal
2 Flashing signal
o413 Movement 0 - 7 0
0 Disabled
1 Constant signal in the opening movement
2 Constant signal in the closing movement
3 Constant signal in the opening and closing movement
4 No signal during movement, used in combination with o410, o411 and o412.
5 Flashing signal in the opening movement
6 Flashing signal in the closing movement
7 Flashing signal in the opening and closing movement
o414 Delayed switch-o Switch o aer the specied time For
example to switch o lighting a specied time aer closing
0.00-9.59 minutes 0.00
o420 Warning time before start 0.00-9.59 minutes 0.00
o421 Warning function in combination with o420 1 - 8 2
1 Constant signal before automatic closing
2 Constant signal before park and automatic closing
3 Constant signal before close signal, park and automatic closing
4 Constant signal before all signals
5 Flashing signal before automatic closing
6 Flashing signal before park and automatic closing
7 Flashing signal before close signal, park and automatic closing
8 Flashing signal before all signals
