21
Programmable output 6
No. Name Range Factory Setting
o600 Function of output 1 0 - 4 0
0 Disabled
1 Position indication/Movement/Warning. Signal as congured in o610 – o622
2 Presence detection/Direction sensing. Signal as congured in o691
3 Lock
4 Alarm output Signal as congured in o630 – o642
o610 Open position 0 - 1 0
0 Disabled
1 Constant signal
o611 Mid position 0 - 1 0
0 Disabled
1 Constant signal
o612 Closed position 0 - 1 0
0 Disabled
1 Constant signal
o613 Movement 0 - 4 4
0 Disabled
1 Constant signal in the opening movement
2 Constant signal in the closing movement
3 Constant signal in the opening and closing movement
4 No signal during movement, used in combination with o610, o611 and o612.
o614 Delayed switch-o Switch o aer the specied time For
example to switch o lighting a specied time aer closing
0.00-9.59 minutes 0.00
o620 Warning time before start 0.00-9.59 minutes 0.00
o621 Warning function in combination with o620 1 - 4 2
1 Constant signal before automatic closing
2 Constant signal before park and automatic closing
3 Constant signal before close signal, park and automatic closing
4 Constant signal before all signals
o622 Function during warning time 1 - 2 1
1 Output signal disabled during warning in other output
2 Output signal as congured in o610-o613
