• Fence alarm
Outputs o1 or 2 are available for fence alarms. Note that i1+i1 are two common inputs for o1 and o2. If there is a
voltage drop, these outputs are open, NO. Remember that the outputs must be connected so that the fence alarm is
activated if a cable is detached, there is a break in a cable or the EP104 loses its power supply. Specify the following
settings to use output 1 for fence alarm.
o100 = 1, Position indication.
o110 = 1, Signal in open position.
o111 = 1, Signal in mid position.
o113 = 3, Signal in opening/closing movement.
o114 = Delay in switch-o, at least 1 second according to alarm manufacturer's instructions.
o120 = Warning test before start, according to the alarm manufacturer's instructions.
o121 = 4, Constant signal before all movements.
o122 = 2, Output signal as congured in o110-o113.
