6
• Channel list, o-channels
Programmable output 1
No. Name Range Factory Setting
o100 Function of output 1 0 - 4 1
0 Disabled
1 Position indication/Movement/Warning. Signal as congured in o110 – o122
2 Presence detection/Direction sensing. Signal as congured in o191
3 Lock
4 Alarm output Signal as congured in o130 – o142
o110 Open position 0 - 1 1
0 Disabled
1 Constant signal
o111 Mid position 0 - 1 0
0 Disabled
1 Constant signal
o112 Closed position 0 - 1 0
0 Disabled
1 Constant signal
o113 Movement 0 - 4 4
0 Disabled
1 Constant signal in the opening movement
2 Constant signal in the closing movement
3 Constant signal in the opening and closing movement
4 No signal during movement, used in combination with o110, o111 and o112.
o114 Delayed switch-o Switch o aer the specied time For
example to switch o lighting a specied time aer closing
0.00-9.59 minutes 0.00
o120 Warning time before start 0.00-9.59 minutes 0.00
o121 Warning function in combination with o120 1 - 4 2
1 Constant signal before automatic closing
2 Constant signal before park and automatic closing
3 Constant signal before close signal, park and automatic closing
4 Constant signal before all signals
o122 Function during warning time 1 - 2 1
1 Output signal disabled during warning in other output
2 Output signal as congured in o110-o113
