ENGLISH
25
Technical specifications JETCOM 102 60Hz
Flow rate (l/min-m3/h) max 60-3,6
Head Hm max 53,8
Pumped liquid temperature From +5°C to +35°C
Maximum system pressure Max 6 bar
Maximum mains pressure Max 4 bar
Minimum mains flow rate Min 10 lt/min
Maximum usage height 15 m
Power supply 1 phase Volt 220-230 Hz60
Maximum absorbed power W 1100
IP protection class 20
Ambient temperature Min +5°C Max +40°C
Tank material PE
Mains water pipe dimensions 3/4”
Discharge pipe dimensions 1”
Suction pipe dimensions 1”
Overflow dimensions DN 50
Max. altitude m 1000
Water type ph 4-9
Recovery tank level sensor ON/OFF float with 20 meters of cable
Weight in Kg empty
Weight in Kg running
18
33
3.1 Dimensions
Figure 02
