dacell DN520N - Page 29

PAGE 28 / 53
N.G Relay “ON” time setting (t5) (Only for F21-03, 04, Check mode)
F28
10
00
∫
99
N.G Replay “ON” time setting.
This relay will be “ON” after “t3” delay time.
01 setting : N.G relay “ON” during 0.1sec.
99 setting : N.G relay “ON” during 9.9sec
Communication setting
Parity Bit selection Mode
F30
●
0
No Parity
1
Odd Parity
2
Even Parity
Serial Communication Speed selection
F31
0
115,200bps
1
76,800bps
2
57,600bps
3
38,400bps
4
28,800bps
5
19,200bps
6
14,400bps
●
7
9,600bps
8
4,800bps
9
2,400bps
Serial I/F Mode setting (Under F33-00 setting, only)
F32
●
0
Steam Mode : Continuous Data transfer
1
Finish Mode : Single time data transfer, after Finish relay “ON”
- When Finish Relay output, Data will be output.
2
Manual Mode : Single time data transfer, when print key input
Serial I/F Transference method setting
F33
●
0
Simplex Mode
1
Duplex Mode / Command Mode
2
LCD Mode
3
Not Use
