dacell DN520N - Page 31

PAGE 30 / 53
4
28,800bps
5
19,200bps
6
14,400bps
●
7
9,600bps
8
4,800bps
9
2,400bps
Serial I/F Mode setting (Under F43-00 setting, only) – Port 2(Option)
F42
●
0
Steam Mode : Continuous Data transfer
1
Finish Mode : Single time data transfer, after Finish relay “ON”
- When Finish Relay output, Data will be output.
2
Print Mode : Single time data transfer, when print key input
Serial I/F Transference method setting – Port 2(Option)
F43
●
0
Simplex Mode
1
Duplex Mode / Command Mode
2
Not Use
3
LCD Mode
4
Not Use
5
Not Use
Transferred Data Format– Port 2(Option)
F45
●
0
Format 1.
1
Format 2. (Format 1 + time)
2
Format 3.
Data Transference count setting – Port 2(Option)
F47
0
About 40times/sec
1
About 30times/sec
2
About 20times/sec
●
3
About 15times/sec
4
About 10times/sec
5
About 5times/sec
6
About 3times/sec
