Dacor 100500 - Design Specifications; Product Dimensions; Door Swing Dimensions

2
dooR swing dimensions
The area to the left and the right of the appliance must permit
both doors to open to a minimum of 90°. Allow a minimum of 2
1/2” (64mm) space between the side of the refrigerator doors and
a corner wall.
NOTE: More clearance may be required if using an overlay panel
or custom handles.
PRoduCT dimensions
◊ Thedepthfromthefrontofthetopgrill(w/odecoratorpanel)
to the back of the refrigerator chassis is 25 1/4” (641mm).
◊ Thedepthfromtherearofthetopgrilltothebackofthe
refrigerator chassis is 23 13/16” (605mm).
◊ Thepowercordis40”(1016mm)long.
◊ Theheight
from the top of the top grill to floor with the
leveling legs in the down position is 83 3/8” (2118mm)
◊ The height from the top of the top grill to floor with the
leveling legs in the fully extended position is 84 5/8”
(2149mm)
◊ The chassis width from the chassis edge to the chassis edge
for 42-inch is model 41 1/4” (1048mm), 48-inch is model 47
1/4” (1200mm).
◊ The overall width from the trim edge to the trim edge for 42-
inch model is 42 1/16” (1068mm), 48-inch model is 48 1/16”
(1221mm).
design sPeCifiCaTions
