Dacor 36” - Installation Specifications; Location Requirements

2
pRoduCT dimensions
◊ Thedepthfromthefrontofthedoor(w/odoorhandles)to
thebackoftherefrigeratorchassisis271/8”(689mm).
◊ Thedepthofthecabinetlessdooris24”(610mm).
◊ Thepowercordis40”(1016mm)long.
◊ Theheight
from the top of the refrigerator to floor with the
levelinglegsinthedownpositionis701/8”(1781mm)
◊ The height from the top of the refrigerator to floor with
design speCifiCaTions
insTallaTion speCifiCaTions
Tools and paRTs
IMPORTANT:
◊ Installer: Leave these Installation Instructions with the
homeowner.
◊ Homeowner: Keep these Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
Tools needed:
Make sure that you have the necessary tools and materials
available for a proper installation.
◊ Phillips screwdriver set
◊ Slotted screwdriver set
◊ Torx drive screwdriver set
◊ Providesufficientlength8’(2.4m)toallowforaminimumof
a24”(610mm)diameterserviceloopof1/4”(6mm)copper
tubingandsaddlevalveforthewaterline(Donotuseself-
piercingvalves)
◊ Copper tubing cutter
◊ Level-2’(.6m)and4’(1.2m)recommended
◊ ApplianceDollyabletosupport700lbs(317kg)and
adequate manpower to handle the weight of the appliance
◊ Various sized pliers
◊ Allen wrench set
◊ 3/8” hex bolt nut driver or socket set
◊ Crescent wrenches
◊ Cordless drill and assorted drill bits
loCaTion RequiRemenTs
Your Dacor
®
refrigerator can be recessed in an opening between
cabinets or installed at the end of a cabinet run using a side panel
to enclose the refrigerator.
WARNING
EXPLOSION HAZARD – Keep flammable material and vapors,
such as gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
IMPORTANT:
◊ Observe all governing codes and ordinances.
◊ Do not install the refrigerator near an oven, radiator, or other
heat source, nor in a location where the temperature will fall
below 55°F(13°C).
◊ Floor must support the refrigerator weight, more than 600lbs
(272kg),doorpanelsandcontentsoftherefrigerator.
◊ Ceiling height must allow for side tipping radius.
◊ Location should permit doors to open fully.
the leveling legs in the fully extended position is 71 1/4”
(1810mm)atthefrontoftheunitand7011/16”(1796mm)at
the rear of the unit.
◊ The width from the refrigerator from edge to is 35 5/8”
(905mm).
dooR swing dimensions
The area to the left and the right of the appliance must permit
both doors to open to a minimum of 90°. Allow a minimum of 2
1/2”(64mm)spacebetweenthesideoftherefrigeratordoorsand
a corner wall.
◊ Masonite, plywood, 1/8” pressed fiberboard, cardboard or
other suitable material to protect finished flooring
◊ Appropriate materials to cover and protect the home and its
furnishings during installation
