5
NOTES:
1. The electrical box and water shut off valve (for model
CM24P-1) should be located in an adjacent cabinet.
2. The electric cord is located in the lower right rear
corner on the back of the unit.
3. Connection to a water supply hose larger than 1/4”,
requires a 1/4-19 BSPP female thread hose fitting.
4. Do not install the unit in a unrestrained free-standing
cabinet.
5. To prevent damage to the appliance, do not set it on
the floor or counter prior to installation.
locatIon requIrements
• Dacor
®
cannot be held responsible for damage to
property or injury to persons caused by failure to
comply with the installation, maintenance, and safety
instructions contained in this handbook.
• Statutory regulations and the connection specifications
issued by the local power supply company must be
strictly observed.
• The coffee system is supplied with a 60” (1524mm)
long power cord terminated by a three-prong plug. The
power cord is intended to be plugged directly into a
dedicated, wall-mounted electrical receptacle.
• The correct voltage, frequency, and amperage must be
supplied to the electrical receptacle from a grounded,
dedicated, single phase circuit that is protected by a
properly sized circuit breaker or time-delay fuse. If one
is not installed, call a licensed electrician.
• The coffee system must be installed at a safe distance
from other sources of heat, such as home appliances,
in order to avoid an excessive rise in temperature.
• For ventilation purposes, there must be a slot near the
top of the cabinet back. The minimum dimensions are
4” X 12” (10.0 X 30.0cm).
InstallatIon specIfIcatIons
