Dacor DMW2420 - Oven Parts Listing

Technical Service | 14425 Clark Avenue | City of Industry, CA 91745 | PH 800-353-2267 | FAX 909-348-5601
3
Ref # Part # Description
1-1 105418 High Voltage Assembly
1-2 105419 AH Sensor
1-3 105420 Oven Lamp
1-4 101937 Noise Filter
1-5 86805 Fan Motor
1-6 66179 Monitor Switch & Fuse Assembly
1-7 66236 Secondary Interlock Switch
1-8 86794 Magnetron Temperature Fuse
1-9 86795 Cavity Temperature Fuse
1-10 105421 Magnetron
1-11 66245 Turntable Motor
1-12 105422 Power Transformer
1-13 105423 Power Supply Cord
2-1 105424 Base Plate
2-2 105425 Foot
2-3 105426 Outer Case Cabinet
3-1 105427 CPU Unit
3-2 105428 Control Panel Frame Assy
3-3 66337B Open Button Assy
3-4 76170 Open Button Spring
3-5 86780 Screw, 3mm x 10mm
4-1 105429 H.V. Capacitor Band
4-2 105430 Chassis Support
4-3 105431 Latch Hook
4-4 86824 Switch Lever
4-5 105432 Magnetron Duct
4-6 105433 Fan Blade
4-7 105434 Fan Duct
4-8 N/A Oven Cavity (Not Replaceable)
4-9 105435 Waveguide Cover
4-10 105436 Turntable Motor Packing
4-11 105437 Sensor Duct
4-12 105438 Cushion
DMW2420 - Oven Parts
