English 31
Installation
STEP 6 Connect the water dispenser line
A water dispenser with a lter is one of the helpful features on your new refrigerator. To
help promote better health, the water lter removes unwanted particles from your water.
However, it does not sterilize or destroy microorganisms. You may need to purchase a
water purifying system to do that.
The water line also connects to the ice maker. For the ice maker to operate properly,
water pressure of 20-125 psi is required.
If the refrigerator is installed in an area with low water pressure (below 20 psi), you can
install a booster pump to compensate for the low pressure.
After you have connected the water line, make sure the water storage tank inside the
refrigerator is properly lled. To do this, press the water dispenser lever until water runs
from the water outlet.
NOTE
Water line installation kits are available at extra cost from your retailer. We
recommend using a water line installation kit that contains copper tubing and a
1
/4"
(6 mm) compression nut.
Use the new hose-sets supplied with the appliance only. Do not re-use an old hose set.
A
B
C
1. Shut off the main water source.
2. Insert the pipe clamp (B) and the
shutoff valve (C) into the cold water
line (A).
A
B
3. Connect the water line installation kit
(A) to the shutoff valve (B).
DACOR_RF8000MC_DA68-03563J-00_EN.indd 31 2017-03-09  11:32:31
