Product Dimensions
Side View:
The depth from the front of the top grille to the back of the 
refrigerator cabinet is 25³⁄8” (64.5 cm).
The power cord is 84” (213 cm) long. 
The water line attached to the back of the refrigerator is 5 ft 
(1.5 m) long.
Height dimensions are shown with leveling legs extended ¹⁄ 
8”
(3 mm) below the rollers.
* When leveling legs are fully extended to 1¼” (3.2 cm) below
rollers, add 1¹⁄
8” (2.9 cm) to the height dimensions.
Top View:
Model Width A
EF42, IF42 41 ¼” (104.8 cm)
EF48, IF48 47 ¼” (120.0 cm)
Installation Requirements
Front View:
Width dimensions were measured from trim edge to trim edge. 
Height dimensions are shown with leveling legs extended ¹⁄  8”
(3 mm) below the rollers.
Model Series Width B (Trim edge to trim edge)
EF42, IF42 42 ¼” (107.3 cm)
EF48, IF48 48 ¼” (122.6 cm)
*When leveling legs are fully extended to 1¼” (3.2 cm) below
rollers, add 1¹⁄
8” (2.9 cm) to the height dimensions.
*3 1/2” (8.9 cm)
23 1/2”
(59.7 cm)
25 3/8”
(64.5 cm)
*83 3/8”
(211.8 cm)
84” (213.4 cm)
Power Cord
25 3/8”
(64.5 cm)
A
B
(see following chart)
*83 3/8”
(211.8 cm)
