5
Planning the Installation
9 1/8" ***
(232mm)
23 3/4"
(603mm)
26 1/2"
(673mm)
27" **
(686mm)
16"
(406mm)
Cut-out for outdoor grill
Overall height
Overall
width
** Total depth from back to front of knobs is 28 5/8” (727mm)
*** Total height with cover is 12” (305mm)
Door depth: 1/4” 6mm)
OBSB162
OBAD SERIES ACCESSORY DOORS
(OBAD36 SHOWN)
Model
Number
Overall
Width
Overall
Height
OBAD20
(Single door)
19 1/2”
(495mm)
21”
(533mm)
OBAD36
(Dual door)
35 7/8”
(911mm)
21”
(533mm)
