Dacor Preference SGM466B - Installation Specifications; Product Dimensions

3
Installation Specifications
WARNING
Observe all governing codes and ordinances during planning and installation. Contact your local building department for
further information.
30"
(762 mm)
1 5/8" (41 mm)
Bottom of base
to cooking surface
27 5/8" *
(702 mm)
* including embosses/screws in side of chassis
19 1/2" *
(495 mm)
21"
(533 mm)
4" (102 mm)
Chassis height
36"
(914 mm)
33 1/2" *
(851 mm)
* including embosses in side of chassis
19 1/2" *
(495 mm)
21"
(533 mm)
1 5/8" (41 mm)
Bottom of base
to cooking surface
4" (102 mm)
Chassis height
* including embosses/screws in side of chassis
46"
(1168 mm)
44 5/8" *
(1133 mm)
19 1/2" *
(495 mm)
21"
(533 mm)
1 5/8" (41 mm)
Bottom of base
to cooking surface
4" (102 mm)
Chassis height
Model SGM466
Model SGM304
Model SGM365
All tolerances ±1/16” (±1.6 mm) unless otherwise noted.
Product Dimensions
