REMOTE CONTROL OF IDEA AMPLIFIERS
• Several amplier units (up to 32 ID address-
es) can be remotely controlled with a single
network cable according to the connections
shown in the gure.
CONTROLLO IN REMOTO AMPLIFICATORI
IDEA
• È possibile controllare a distanza con un uni-
co cavo di rete diverse unità di amplicatori (
no a 32 indirizzi ID) secondo i collegamenti
riportati in gura.
