TIP
Using puripot more effectively
15
For concrete walls /
tile walls
※
How to install (Frame Type)
Groove : angle between the wall
and the top of the body becomes 7˚
1
Groove : angle between the wall
and the top of the body becomes 12˚
2
14
Screw the mounting bracket to
the wall using the screws provided.
Mount the main body to
one of the grooves on the bracket.
The two grooves of the bracket are designed to provide two different mounting
angles. Select the groove of your preferred angle and install the main body.
1 2
7˚ 12˚
To increase the air cleaning efficiency,
install puripot in the position facing
the window, air conditioner or fan.
If the room has a strong odor, please
open the window and use puripot
at the same time.
To Next Page
