[CK3520]
Item
Model
CK3520 CK3520H CK3520SEB CK3520HSEB CK3520CHSEB
Engine
Model 3H-TM4-U 3H-TH4-U 3H-TM4-U2 3H-TH4-U2 3H-TH4-U2
No. of cylinders 3 3 3 3 3
Total displacement cc (cu) 1,826 (111.4) 1,826 (111.4) 1,826 (111.4) 1,826 (111.4) 1,826 (111.4)
Bore and stroke in. (mm)
3.4 x 4.03
(87 × 102.4)
3.4 x 4.03
(87 × 102.4)
3.4 x 4.03
(87 × 102.4)
3.4 x 4.03
(87 × 102.4)
3.4 x 4.03
(87 × 102.4)
Engine gross power
HP (kW) 34.9 (26) 34.9 (26) 34.9 (26) 34.9 (26) 34.9 (26)
Rated revolution rpm 2,600 2,600 2,600 2,600 2,600
Capacity
Fuel tank U.S gal (L) 8.98 (34.0) 8.98 (34.0) 8.98 (34.0) 8.98 (34.0) 8.98 (34.0)
Transmission uid U.S gal (L) 5.8 (22.0) 5.8 (22.0) 5.8 (22.0) 5.8 (22.0) 5.8 (22.0)
Coolant
(Engine Only)
U.S gal (L) 0.89 (3.4) 0.89 (3.4) 0.89 (3.4) 0.89 (3.4) 0.89 (3.4)
Engine oil U.S gal (L) 1.6 (6.0) 1.6 (6.0) 1.6 (6.0) 1.6 (6.0) 1.6 (6.0)
Front axle oil U.S gal (L) 1.6 (6.0) 1.6 (6.0) 1.6 (6.0) 1.6 (6.0) 1.6 (6.0)
Driving
system
Clutch Dry dual Dry single Dry Single none none
Transmission
Shuttle shift N/A HST Synchro shuttle HST HST
Main shift type
1st
・
3rd: Con-
stant mesh
2nd
・
Reverse:
Synchro mesh
-
Synchromesh /
4 Speed
- -
Range shift type
Constant mesh
/ 3 Speed
Constant mesh
/ 3 Speed
Constant mesh
/ 3 Speed
Constant mesh
/ 3 Speed
Constant mesh
/ 3 Speed
No. of speeds F9 × R3
3
F12 × R12
3 3
