UNIVERSAL SYMBOLS
Various universal symbols have been used on the instruments and controls of your KIOTI tractor.
Below is a list of the universal symbols and their meanings.
Fuel-Level
Engine Coolant-Temperature
Parking Brake
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
Power Take-Off Clutch Con-
trol-ON Position
Power Take-Off Clutch Con-
trol-OFF Position
Differential Lock
Position Control-Lowered Po-
sition
Hazard Warning Lights
Headlight-Low Beam
Headlight-High Beam
Four-Wheel Drive-ON
Fast
Slow
Creep
High Range
Middle Range
Low Range
Coolant
Preheat
QT lamp
H:High speed travel light
M:Middle speed travel light
L:Low speed travel light
Neutral Position
Single brake light
H
L
M
N
