1. Turn the key switch to "ON", check
the amount of fuel by fuel gauge.
2. If the needle on the fuel gauge is
close to "E" or the fuel level is low,
open the fuel tank filler cap and
add the fuel.
3. After adding the fuel, close the fuel
tank ller cap.
•
Do not smoke while refueling.
•
Add the fuel in a well-ventilat-
ed area.
•
-
fore refueling.
•
Dirt or sand contained in fuel
strainer when refuelling.
CAUTION
CHECKING TRANSMISSION FLUID
LEVEL(D)
1. Park the machine on a at surface,
lower the implement and shut off
engine.
2. Depress the brake pedals and ap-
ply the parking brake.
3. Set all shift levers into the neutral
position.
4. Stop the engine.
•
it off at once, or it may cause
•
If unit is not used for a long
time, make sure the fuel vis-
cosity is suitable for the cold
weather.
(1) Gauge (2) Oil Inlet
(A) Oil level is acceptable within this range
Te7O704A
