NS4710 / NS6010 / NS4710H / NS5310H / NS6010H
3
-
2
GENERAL SPECIFICATIONS
EXTERNAL DIMENSIONS
E1 : Front wheel tread E2 : Rear wheel tread
These dimensions are measured with standard tires (AG) installed on the ROPS model tractor.
mm (in.)
ITEM
MODEL
NS4710(H)
NS5310H
NS6010(H)
1. Overall length (A1) 3,820 (150.4)
2. Overall length (A2) 3,465 (136.4)
3. Overall width (B) 1,705 (67.1) 1,684 (66.3)
4. Overall height (C) 2,587 (101.9) 2,648 (104.3)
5. Wheel base (D) 1,918 (75.5)
6. Tread (E1) 1,297 (51.1.) 1,381 (54.4)
7. Tread (E2) 1,360 (53.5) 1,334 (52.5)
8. Ground clearance (F) 340 (13.4) 390 (15.4)
E
2
B
1
E
D
A
2
C
2
C
1
A
1
F
H11O301A
